Kleintek W Series Labeller: Australian-Made Automatic Wrap-Around Labelling

🇦🇺 Designed and made in Australia

The Kleintek W Series is an automatic wrap-around labeller built by Kleintek in Euroa, Victoria. It’s built without compromise, using high-quality servo, PLC and drive components, and designed to run inline with your filling and capping machines. It’s available from Rentafill to hire or buy.

Kleintek W Series at a glance

  • Automatic wrap-around labelling for round containers, inline or standalone.
  • Servo label feed with ±0.1 mm label stop accuracy.
  • Omron PLC and drives, Motovario motors.
  • 316 stainless steel and anodised aluminium construction.
  • Comes with the ICP Spacer Wheel for automatic container spacing.
  • Australian made, 12-month warranty, available to hire or buy.

Kleintek W Series automatic wrap-around labeller

Built to Run Inline

Most labellers come on their own conveyor, so containers have to be transferred from your filling line onto the labeller. The W Series can be supplied without a conveyor and attached directly to an existing production line, so containers flow straight from filling and capping into labelling with no transfer.

Prefer a standalone machine? It also comes with its own conveyor, with adjustable height to suit your other equipment, levelling feet and lockable castors so it can be moved around the production floor.

What Makes It Different

Servo label feed

A servo-driven label feed controls dispensing speed and stops each label accurately, reducing mislabelled containers.

Proven components

Omron PLC and drives and Motovario motors, chosen for reliability and long service life.

Easy to run

Graphical setup guides on the control screen mean operators need minimal training.

Hygienic build

316 stainless steel and anodised aluminium, suited to food, cosmetic and pharmaceutical production.

Built Around Your Job

Every W Series can be configured to suit your containers and labels. Options include:

  • Clear label sensing for no-look labels.
  • Inkjet coders and thermal printers to print batch codes and dates.
  • Container orientation.
  • The ICP Conveyor Spacer Wheel, which spaces containers automatically for smooth, consistent labelling.

Specifications

Specification Kleintek W Series
Label dispensing speed 3 to 32 m/min
Label stop accuracy ±0.1 mm
Conveyor speed 6 to 25 m/min
Power 240 V 50 Hz single phase
Air supply 5 bar
Construction 316 stainless steel and anodised aluminium
Warranty 12 months (T&Cs apply)
Made in Euroa, Victoria, Australia

When to Choose the W Series

The W Series is the labeller we point customers to when they need high-quality automatic labelling on a filling line, especially for long or full-wrap labels. For hand-fed work, a semi-automatic labeller such as the Compact-A-Wrap may be all you need. Labelling round containers has its own challenges, covered in what to check before you print.

You can hire the W Series and run your own containers and labels first. We’ll set it up to suit before it leaves us.

Frequently Asked Questions

Common questions about the Kleintek W Series labeller.

Who makes the Kleintek W Series labeller?

The W Series is designed and built by Kleintek in Euroa, Victoria, and is available from Rentafill to hire or buy.

Can the W Series attach to my existing production line?

Yes. It can be supplied without a conveyor and attached directly to an existing line, or with its own conveyor as a standalone labeller.

How accurate is the Kleintek W Series?

The servo label feed stops each label to within ±0.1 mm.

Can it print batch codes and dates?

Yes. The W Series can be fitted with inkjet coders or thermal printers to print codes onto the label.

What warranty does the Kleintek W Series have?

New Kleintek W Series labellers carry a 12-month warranty (T&Cs apply).

Label Inline With Your Filling Line

Hire the Kleintek W Series and run your own containers and labels, or talk to us about buying one.

View the W SeriesHire the W SeriesCall 02 9987 1871
