BenchMax Electric Label Applicator

Price on quote

A labelling machine that boasts flexibility and precision.

Australian-built, the BenchMax by Great Engineering is the strongest and most reliable labelling machine of its calibre. Fast, accurate, and flexible, the label applicator can handle any round container from 8mm to 250mm diameter.

Add to Quote
Category:

Boasting a reputation of being the most accurate labelling machine in the world, the Australian-built BenchMax can quickly apply a single label, a full wrap-around label, or a front and back label in one simple operation. The labelling machine promises millimetre precision of its back label positioning.

The BenchMax features a star wheel sensor, which accurately detects a greater range of labels with proven reliability. Its controlled label ejection ensures uniform application of the label to the surface of your products. The BenchMax is fitted with a footswitch and suitable for interfacing with a printer to produce barcodes and batch information.

With the inexperienced user in mind, the BenchMax requires no special skills or training to label efficiently and effectively.

  • Round container only
  • Anodised 6061 Aluminium
  • Food Grade Stainless Steel shafts and bolts.
  • Dimensions w x d x h (mm) 590 x 610 x 440
  • Weight 32Kg
  • 110 or 240AC <1AMP
  • Container Minimum diameter 8mm
  • Container Maximum diameter 110mm standard
  • Container Maximum 220mm with removable or extended handle
  • Sensor Type – on edge, no registration mark required.
  • Automatic sensor for hands free application.
  • Removable handle – works the same as the extended handle for containers up to 110mm in diameter. Can be removed for larger containers that are pre-filled.
  • Extended Handle – Will only label large containers from 110mm to 220mm in diameter (if needing to label empty containers).

Supported Labels:

  • Single, front & back, or wrap-around labels.
  • Pressure sensitive, die-cut, roll-formatted, Fan Folded,
  • Opaque, clear, translucent.

Label Size

  • Thickness: Min. 0.02mm
  • Length: Greater than 25mm
  • Height: Min. 10mm to Max. 230mm
  • Direction: Left Hand Leading Edge (Internal or Externally wound)

Label Roll Dimensions

  • Diameter:Maximum 300mm
  • Core Diameter: 38mm and 76mm

Label Direction
